BestPack Auto Edge AT Case Sealer
SKU IPS-AR4E
The BestPack® AT SERIES operator free, four outer edge carton sealing machines, using pressure sensitive tape. These machines are designed to eliminate costly hand taping of the four outer edges where pilfer proofi ng and protection of your product from outside environment is necessary. The AT model is designed for uniform edge sealing applications
The units are designed with an automatic 90° box turner. The AT4E edge sealers require 80 PSI and 10 CFM of air, and standard 110V 60 CPS, single phase current. (Unless otherwise specified at time of order.)
Need a live product specialist? Please call 800-277-7007Specifications
| Standard Equipment | |
|---|---|
| Patented Brushing System for even application of tape. | |
| Four Pop out Pressure Sensitive Tape Heads with patented tab adjustment | |
| Locking Heavy-duty Casters/or Pegs. | |
| Bottom Tape Air Blowers | |
| Four Belt Drive | |
| 90 Degree Box Turner | |
| Low Tape Sensor and Warning Light | |
| Maintenance Free, Oil-Less Air Cylinders | |
| Instruction Manual | |
| Type | Equipment |
| Specifications (long) | Machine & Carton Specifications |
| Power Requirements | 110 Volt 60 CPS Single Phase Current |
| Air Requirements | 80 PSI 10 CFM |
| Speed | Up to 6 cartons/minute |
| Tape Head | Standard |
| Machine Dimensions ¹ | L |
| W | 53.15" |
| H | 67.32" |
| Carton Min/Max Range² | L |
| W | 9.84" - 23.62" |
| H | 9.84"- 23.62" |
| ¹ Machine weight and dimensions may vary depending on carton sizes. Please view brochure for complete machine specifications. | |
| ² Carton ranges are fully customizable. Please inquire with our sales team with your specific requirements. | |
Features
Rugged Construction
Operator Free Design
Height/Width Adjustments on either side of Machines
Tape Roll Lengths: 1000 yd., 1500 yd., 2000 yd.
Heavy Duty Frame
UL Approved Electrical Parts
Designed for Uniform Carton Sizes
2" Tape Head Available
Operator Free Design
Height/Width Adjustments on either side of Machines
Tape Roll Lengths: 1000 yd., 1500 yd., 2000 yd.
Heavy Duty Frame
UL Approved Electrical Parts
Designed for Uniform Carton Sizes
2" Tape Head Available
Notes
Overview
The BestPack AT SERIES operator free, four outer edge carton sealing machines, using pressure sensitive tape. These machines are designed to eliminate costly hand taping of the four outer edges where pilfer proofing and protection of your product from outside environment is necessary. The AT model is designed for uniform edge sealing applications
The units are designed with an automatic 90? box turner. The AT4E edge sealers require 80 PSI and 10 CFM of air, and standard 110V 60 CPS, single phase current. (Unless otherwise specified at time of order.)
All units are available in standard finish or stainless steel.
Standard 3" Tape Head; 2" Tape Head available
The BestPack AT SERIES operator free, four outer edge carton sealing machines, using pressure sensitive tape. These machines are designed to eliminate costly hand taping of the four outer edges where pilfer proofing and protection of your product from outside environment is necessary. The AT model is designed for uniform edge sealing applications
The units are designed with an automatic 90? box turner. The AT4E edge sealers require 80 PSI and 10 CFM of air, and standard 110V 60 CPS, single phase current. (Unless otherwise specified at time of order.)
All units are available in standard finish or stainless steel.
Standard 3" Tape Head; 2" Tape Head available
Options
Optional Equipment
Infeed/Exit Conveyor
Stainless steel
No Tape on Carton Sensor
Low Tape Sensor
Spare Parts Kit
Infeed/Exit Conveyor
Stainless steel
No Tape on Carton Sensor
Low Tape Sensor
Spare Parts Kit
