Part # SKU Product Name Get Quote
2 290391 Bearing - Housing
3 290392 Dowel Pin - Strap Guide
4 288084 Dowel Pin - Jaws
5 40281 Dowel Pin - Base Housing
6 54544 Cap Screw - Lifter Pad
7 290393 Set Screw
8 40282 Screw - Long Base
9 40283 Screw - Medium Base
10 40284 Screw - Short Base
12 254790 Jaw Screw
13 290394 Front Cover
14 290395 Bearing - Front Cover
15 159151 Front Cover Screw
16 24812 Clutch Plug
17 54543 Spirol Pin
19 83714 Eccentric Shaft
20 289191 Lifter - Right
21 59963 Bearing - Upper Tool
22 38640 Upper / Lower Jaw
23 289192 Lifter Crank
24 254791 Dowel Pin - Cutte Knife
25 24813 Cutting Knife
26 289190 Lifter - Left
27 50194 Knife Bed
29 24811 Tension Wheel
30 87858 Rocker
31 87859 Bearing - Rocker
32 87860 Roller Clutch - Rocker
33 39143 Tension Spring
34 59964 Bearing Inner Ring
35 184208 Cutting Lever
36 187402 Cutter Lever Grip
37 187047 Tansport Shaft
39 60122 Retaining Ring - Transport Shaft
40 290396 Grooved Rocker Pin
41 87807 E-Clip - Grooved Rocker Pin
42 94118 Left / Right Strap Guide
43 59859 Left / Right Strap Guide Screw
45 290397 Tension Lever
46 290398 Tensioner Lever Grip
47 290399 Bearing - Tension Lever
48 290400 Lock Plate - Knife Bed
49 290401 Lock Plate - Clutch Plug
50 60120 Spacer - Front Strap Guide
51 187048 Front Strap Guide
52 39899 Depth Adjust Screw
53 39900 Depth Adjust Jam Nut
59 288081 Feedwheel Shim .010"
60 288082 Feedwheel Shim .030"
61 288083 Feedwheel Shim .015"
62 290402 Rocker Shim .010"
63 290403 Rocker Shim .025"
72 290404 Lifter Pad
85 290405 Top Cover
86 290406 Top Cover Screw
KIT (18) 40330 Housing
