BXT2-16

REQUEST MORE INFO >

Part #	SKU	Product Name
1	157174	Base Plate Complete, Incl. Pos 3-5
3	107656	Slide Bearing 10/12 X 15
4	107651	Slide Bearing 12/14 X 8
5	280953	Cylinder Pin 10 H6 X 55
7	107626	Tooth Plate Below
8	107644	Set Screw
12	157195	Ball Bearing 10/22 X 6
13	157184	Spacer Ring
17	157193	Ball Bearing 10/22 X 6
33	197622	Cylinder Pin 4 M6 X 20
35	157185	Cam Disk
37	157169	Planetary Wheel 2. Step
38	107627	Tension Wheel
40	107623	Rocker
43	107646	Strap Stop, Front, 13 Mm
45	107662	Counter Sunk Screw, M3 X 8
46	107630	Tooth Plate
47	157217	Counter Sunk Screw
48	157171	Motor Comple Incl. Pos 49
49	193015	Brushcover-Set
54	157191	Ball Bearng 15/24 X 5
55	197621	Tothed Belt Wheel Complete, Incl. Pos. 54,57.
58	197619	Bevel Wheel Complete, Incl. Pos. 54, 60
63	157232	Bushing Complete, Incl. Pos. 77
65	157233	Needle Bushing 12/18 X 12
66	157194	Ball Bearing 12/24 X 6
68	157234	Ecentric Shaft
69	157180	Ecentric Shaft
70	93701	Disk
73	107643	Tothed Belt
75	197620	Swivel Bearing Complete, Incl. Pos. 77
77	157205	Ridget Pin, 3 X 8 Din 1469
78	107654	Tension Spring
79	157206	Retaining Ring, A 23
81	157235	Connecting Rod
82	157178	Shaft
84	157168	Washer
86	197657	Counter Sunk Screw, M3 X 8
87	107628	Welding Shoe
89	157179	Safety Plate
90	107635	Ball Bushing
91	107649	Cover Plate
93	106657	Tooth Plate Top
94	157166	Compression Spring
95	107631	Cutter Knife
96	107650	Flanged Bushing
100	107637	Cover Tensioning
102	107640	Strap Guide, 13Mm
104	197656	Counter Sunk Screw, M4 X 12
109	157183	Rocker Lever Complete, Incl. Pos. 111-113
111	107667	Threaded Bolt, M8
112	197631	Ridget Pin, 4 X 30
113	157209	Cylinder Pin, 4 X 30
114	157182	Blocking Paw
117	197632	Spacer Disk, 10/16 X .5
118	197633	Retaining Ring, 8
121	107655	Tenision Spring
123	197634	Globule Hardened, 8
124	157165	Compression Spring
125	197686	Threaded Bolt, M10
126	107657	Compression Spring
127	107639	Welding Bouton-Set, Incl. 156
130	107636	Cam
132	107642	Micro Switch, Welding
135	157181	Spring Bow
139	157167	Spring
140	197635	Lock, Nut M6
141	107670	Retaining Ring, 4
142	281435	Shaft
146	157176	Cover Welding
147	157186	Strap Guide, 13/16 Mm
148	157189	Strap Stop, 13/16 Mm
149	138992	Hook
150	157188	Threaded Bolt
151	157190	Threaded Bolt
152	107653	Compression Spring
153	281467	Oval Head Screw, M4 X 25
154	157212	Oval Head Screw, M3 X 12
155	157175	Gear Cover
160	157177	Housing Part Left, Black
162	107672	Pt-Screw, Ka 35 X 20
164	107645	Protection Cover
166	157170	Switch Button, Red
167	107652	Compression Spring
168	107641	Micro Switch, Tensioning
170	107624	Motor Cover Complete, Black
171	107629	Contact Plate Complete
172	107619	Printed Circuit Board Digital
173	107674	Pt-Screw, Ka 30 X 10
176	107621	Battery 12V V,4 Ah
177 B	107625	Charger Al60Dv,1419, Usa
177 C	192986	Charger Al60Dv, 1419, Japan
191	157173	Wire Brush
193	157215	Protection Plate
196	157216	Suspension Bow
200	197687	Option: Protection Coverset
